Prestressed Steel Strand

Prestressed Steel Strand
PC Strand, or prestressed concrete steel strand, is a twisted steel cablecomposed of high strength steel wires and is stress-relieved(stabilized)for prestressed concrete or similar purposes.
WhatsApp:+840924083465
Email:summitmetal123@outlook.com
CONTACT US

Product Description

Prestressed Steel Strand

● Steel Wire for Prestressed Concrete:
The product is mainly used to produce prestressed concrete components of various structural shapes using various tensioning techniques. In the construction of large-scale railways, highway bridges, roof trusses, crane beams, industrial and civil prefabricated panels, wall panels, prestressed concrete TV towers, nuclear power plants, and other engineering projects. Produce two surface forms: smooth and spiral ribs. American standards ASTMA416, ASTMA421, British standard BS5896, Japanese standard JISG3536, international standard ISO6934, European standard EN10138

● Steel Strand for Prestressed Concrete :
This product is mainly used for reinforcing prestressed concrete structures. Such as large-span railway and highway bridges, crane beams, geotechnical anchoring engineering, multi-layer industrial factories, coal mines, sports venues, etc. Main executive standard: ASTM A416

● Unbonded Steel Strand for Prestressed Concrete:
Post tensioned unbonded prestressed steel strands are used for cast-in-place floor slabs, prefabricated beams with large loads, and other specially designed structures in large-span and large-span buildings. It has the characteristics of no need for reserved holes, no need for grouting, simple construction, material saving, and easy bending.



Technical parameters of steel strand - American Society for Testing and Materials standard (ASTM A416)





Grade



Nominal

Dia.

(mm)





Tolerance

(mm)



Nominal

section

area

(mm2)



Mass Per

1000m

(Kg/1000m)



Minimum

Breaking

load



Min Load at 1%

Extension

(KN)





Lo≥610mm

(%)

The relaxation at 1000 h (Initial

load to 70% of nominal max load)

(r/%)

Low-Relaxation

Normal-Relaxation



250

[1725]

9.5





±0.40

51.6

405

89.0

80.1

3.5

2.5

3.5

11.1

69.7

548

120.1

108.1

12.70

92.9

730

160.1

144.1

15.20

139.4

1094

240.2

216.2



270

[1860]

9.53



+0.65

-0.15

54.84

432

102.3

92.1

11.11

74.19

582

137.9

124.1

12.70

98.71

775

183.7

165.1

15.24

140.00

1102

260.7

234.6

Product Application

  • 1775551249900060937244790784
  • 1724983128687962864209162240
  • 1724983125687962850678337536
  • 1724983121687962836648390656
  • 1700360854_huge
  • a79728cbbd8040cb9dcee1b7a5e8e557

Packaging and shipping

  • 1
  • 2
  • 3
  • 4
  • 5
  • 9

Factory Display

  • a635e6aa8af749b3b20947091f812fdd
  • 011177a38e499b8b50e0993f29e85558
  • 60a465fb6d089d1e3a0c90958431d3c3
  • 未标题-2
  • 摄图网_600975422_钢铁仓库(非企业商用)-(1)
  • vecteezy_modern-industrial-steel-manufacturing-facility-with-advanced_49740735
  • 0b42940c953e9e845fc286c7d6151ed6
  • a8c2ec4a3945a90482a70e6aabff013f
  • 418cd469d6a99619474e86e46048a5c9
  • bf4177c383f74c00f80e0bca1aae52a7
  • 工厂车间 (4)
  • 5
  • 4ba06389467ca90624596b987abe434be8635cba188343-TdLEpR 拷贝
  • 645f88ceb28016b71deb44d0eca6ae91346ff4f633046-YV9trp
  • 76e854f676be41a74b86935d2042824d

FAQ

1. What are your main products?
We primarily deal in carbon steel (hot-rolled/cold-rolled sheets, coils, pipes, and bars), structural steel (angle bars, channel steel, I-beams, H-beams, square/rectangular tubes, etc.), galvanized products (galvanized sheets, coils, pipes, and profiles), and aluminum products (sheets, coils, profiles, and bars). We can also supply other steel varieties based on customer requirements.


2. Are you a manufacturer or a trader?
We are a comprehensive service provider integrating trading, processing, and distribution. We maintain close partnerships with major steel mills in Vietnam and the surrounding region, ensuring a stable supply chain. Additionally, our in-house processing center offers value-added services, combining the flexibility of a trader with the service capabilities of a processing plant.


3. Do you accept small-batch orders? What is the minimum order quantity (MOQ)?
Yes, we support small-batch and trial orders. The MOQ is typically one container (approx. 20–25 tons), depending on product specifications and dimensions. MOQs for aluminum products can be lower; please contact us for details.


4. What is the typical delivery time?
For standard products, delivery takes 15–30 days after receipt of the deposit, depending on order volume, product type, and current production scheduling. Stock items can be delivered sooner. Delivery times for customized orders will be longer, and we will inform you in advance.


5. What payment methods do you accept?
We generally accept T/T (Telegraphic Transfer) and L/C (Letter of Credit). More flexible payment terms can be negotiated for long-term clients. Specific ratios (e.g., 30% down payment and 70% balance) can be adjusted based on the order value and credit status.


6. What processing services do you offer?
We provide services such as cutting, punching, bending, welding, uncoiling, and leveling. We also offer customized deep processing of profiles based on technical drawings. All processing is performed in-house to ensure quality control and timely delivery.
