Carbon Shipbuilding Steel Plate

Shipbuilding steel plate refers to the carbon and alloy steel plate used in offshore and marine contructions, common grades are A, B, D, E, AH32/36/40, DH32/36/40, and EH32/36/40 which ranged from different strength.

WhatsApp：+840924083465

Email：summitmetal123@outlook.com

Product Description

Carbon Shipbuilding Steel Plate Description

Shipbuilding steel plate refers to hot-rolled steel for the manufacture of ship structures produced in accordance with the requirements of the construction society. Often used as a special steel ordering, scheduling, sales, a ship including ship plates, steel and so on.

The Shipbuilding steel plate can be divided into general strength structural steel and high strength structural steel according to its minimum yield point strength level.

AGICO supplies and exports 2 types of ship steel, medium strength shipbuilding plate and high strength shipbuilding plate. All steel plate product can be manufactured according to Society LR, ABS, NK, GL, DNV, BV, KR, RINA, CCS, etc.

Product Parameters

Product Name	Carbon Shipbuilding Steel Plate
Production Process	Hot Rolling, Cold Rolling
Material Standards	AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc.
Width	100mm-3000mm
Length	1m-12m, or Customized Size
Thickness	0.1mm-400mm
Delivery Conditions	Rolling, Annealing, Quenching, Tempered or Standard
Surface Process	Ordinary, Wire Drawing, Laminated Film

Chemical Composition

Grade	C % ≤	Mn %	Si %	P % ≤	S % ≤	Al %	NB %	V %
A	0.22	≥ 2.5 C	0.10-0.35	0.04	0.40	-	-	-
B	0.21	0.60-1.00	0.10-0.35	0.04	0.40	-	-	-
D	0.21	0.60-1.00	0.10-0.35	0.04	0.04	≥ 0.015	-	-
E	0.18	0.70-1.20	0.10-0.35	0.04	0.04	≥ 0.015	-	-
A32 D32 E32	0.18	0.70-1.60 0.90-1.60 0.90-1.60	0.10-0.50	0.04	0.04	≥ 0.015	-	-
A36 D36 E36	0.18	0.70-1.60 0.90-1.60 0.90-1.60	0.10-0.50	0.04	0.04	≥ 0.015	0.015-0.050	0.030-0.10

Mechanical Properties

Grade	Thickness (mm)	Yieldpoint (Mpa) ≥	Tensile Strength (Mpa)	Elongation (%) ≥	V-impact Test			Cold Bend Test
					Temperature (℃)	Average AKV A kv /J		b=2a 180°	b=5a 120°
						Lengthways	Crosswise
						≥
A	≤ 50	235	400-490	22	—	—	—	d=2a	—
B					0	27	20	—	d=3a
D					-10
E					-40
A32	≤ 50	315	440-590	22	0	31	22	—	d=3a
D32					-20
E32					-40
A36	≤ 50	355	490-620	21	0	34	24	—	d=3a
D36					-20
E36					-40

Product Application

Packaging and shipping

Factory Display

FAQ

1. What are your main products?
We primarily deal in carbon steel (hot-rolled/cold-rolled sheets, coils, pipes, and bars), structural steel (angle bars, channel steel, I-beams, H-beams, square/rectangular tubes, etc.), galvanized products (galvanized sheets, coils, pipes, and profiles), and aluminum products (sheets, coils, profiles, and bars). We can also supply other steel varieties based on customer requirements.

2. Are you a manufacturer or a trader?
We are a comprehensive service provider integrating trading, processing, and distribution. We maintain close partnerships with major steel mills in Vietnam and the surrounding region, ensuring a stable supply chain. Additionally, our in-house processing center offers value-added services, combining the flexibility of a trader with the service capabilities of a processing plant.

3. Do you accept small-batch orders? What is the minimum order quantity (MOQ)?
Yes, we support small-batch and trial orders. The MOQ is typically one container (approx. 20–25 tons), depending on product specifications and dimensions. MOQs for aluminum products can be lower; please contact us for details.

4. What is the typical delivery time?
For standard products, delivery takes 15–30 days after receipt of the deposit, depending on order volume, product type, and current production scheduling. Stock items can be delivered sooner. Delivery times for customized orders will be longer, and we will inform you in advance.

5. What payment methods do you accept?
We generally accept T/T (Telegraphic Transfer) and L/C (Letter of Credit). More flexible payment terms can be negotiated for long-term clients. Specific ratios (e.g., 30% down payment and 70% balance) can be adjusted based on the order value and credit status.

6. What processing services do you offer?
We provide services such as cutting, punching, bending, welding, uncoiling, and leveling. We also offer customized deep processing of profiles based on technical drawings. All processing is performed in-house to ensure quality control and timely delivery.
