API 5CT Steel Pipe

  • API 5CT Steel Pipe
  • API 5CT Steel Pipe
  • API 5CT Steel Pipe
  • API 5CT Steel Pipe

API 5CT Steel Pipe
API is an acronym for the American Petroleum Institute and is considered the most authoritative and comprehensive principle in the oil and gas industry. API 5B and API 5CT are mainly used for oil casing. API 5CT oil casing can be divided into seamless steel pipe and welded steel pipe.
WhatsApp：+840924083465
Email：summitmetal123@outlook.com
CONTACT US

Product Description

API 5CT Steel Pipe Description

API 5CT is a standard technical specification of steel pipes for casing and tubing in oil or gas industries. It can be used in oil or gas drilling and conveying. Commonly used oilfield API-5CT casing steel grades are J55, K55, N80-1, N80Q, P110. Casings are mostly used in oil well drilling. According to the API-5CT standard, pipes can be divided into STC (short thread), LTC (long thread) and BTC (support thread) and their joints.


Product Parameters

Product Name

API 5CT Steel Pipe

Standard

EN/DIN/JIS/ASTM/BS/ASME/AISI etc.

Outer Diameter

Seamless: 1/4"-36"

Welding: 21.3mm-3620mm

Round Tube: 1/2"-10"

Square Tube/Rectangular Tube: 15x15mm-400x600mm

Wall Thickness

Seamless: 1.25mm-50mm

Welding: 1.65mm-65mm

Length

3-12 meters, Support customization

Surface Process

Bright, Polished, Black

Other Services

Machining(cnc), Centerless Grinding(cg), Heat Treatment, Annealing, Pickling, Polishing, Rolling, Forging, Cutting, Bending, Small Machining, etc.



Chemical Composition

Grade

C ≤

Si ≤

Mn ≤

P ≤

S ≤

Cr ≤

Ni ≤

With

V ≤

Als ≤

API 5CT J55

0.34-0.39

0.20-0.35

1.25-1.50

0.020

0.015

0.15

0.20

0.20

/

0.020

API 5CT K55

0.34-0.39

0.20-0.35

1.25-1.50

0.020

0.015

0.15

0.20

0.20

/

0.020

API 5CT N80

0.34-0.38

0.20-0.35

1.45-1.70

0.020

0.015

0.15

/

/

0.11-0.16

0.020

API 5CT L80

0.15-0.22

1.00

0.25-1.00

0.020

0.010

12.0-14.0

0.20

0.20

/

0.020

API 5CT J P110

0.26-035

0.17-0.37

0.40-0.70

0.020

0.010

0.80-1.10

0.20

0.20

0.08

0.020



Mechanical Properties

Grade

Yield Strength (Mpa)

Tensile Strength (Mpa)

API 5CT  J55

379-552

≥ 517

API 5CT  K55

≥ 655

≥ 517

API 5CT  N80

552-758

≥ 689

API 5CT  L80

552-655

≥ 655

API 5CT  P110

758-965

≥ 862



Scope of Application

API 5CT oil casing is mainly used to transport oil, natural gas, coal gas, water and other liquids, gases.

Product Application

  • 1775551249900060937244790784
  • 1724983128687962864209162240
  • 1724983125687962850678337536
  • 1724983121687962836648390656
  • 1700360854_huge
  • a79728cbbd8040cb9dcee1b7a5e8e557

Packaging and shipping

  • 1
  • 2
  • 3
  • 4
  • 5
  • 9

Factory Display

  • a635e6aa8af749b3b20947091f812fdd
  • 011177a38e499b8b50e0993f29e85558
  • 60a465fb6d089d1e3a0c90958431d3c3
  • 未标题-2
  • 摄图网_600975422_钢铁仓库(非企业商用)-(1)
  • vecteezy_modern-industrial-steel-manufacturing-facility-with-advanced_49740735
  • 0b42940c953e9e845fc286c7d6151ed6
  • a8c2ec4a3945a90482a70e6aabff013f
  • 418cd469d6a99619474e86e46048a5c9
  • bf4177c383f74c00f80e0bca1aae52a7
  • 工厂车间 (4)
  • 5
  • 4ba06389467ca90624596b987abe434be8635cba188343-TdLEpR 拷贝
  • 645f88ceb28016b71deb44d0eca6ae91346ff4f633046-YV9trp
  • 76e854f676be41a74b86935d2042824d

FAQ

1. What are your main products?
We primarily deal in carbon steel (hot-rolled/cold-rolled sheets, coils, pipes, and bars), structural steel (angle bars, channel steel, I-beams, H-beams, square/rectangular tubes, etc.), galvanized products (galvanized sheets, coils, pipes, and profiles), and aluminum products (sheets, coils, profiles, and bars). We can also supply other steel varieties based on customer requirements.


2. Are you a manufacturer or a trader?
We are a comprehensive service provider integrating trading, processing, and distribution. We maintain close partnerships with major steel mills in Vietnam and the surrounding region, ensuring a stable supply chain. Additionally, our in-house processing center offers value-added services, combining the flexibility of a trader with the service capabilities of a processing plant.


3. Do you accept small-batch orders? What is the minimum order quantity (MOQ)?
Yes, we support small-batch and trial orders. The MOQ is typically one container (approx. 20–25 tons), depending on product specifications and dimensions. MOQs for aluminum products can be lower; please contact us for details.


4. What is the typical delivery time?
For standard products, delivery takes 15–30 days after receipt of the deposit, depending on order volume, product type, and current production scheduling. Stock items can be delivered sooner. Delivery times for customized orders will be longer, and we will inform you in advance.


5. What payment methods do you accept?
We generally accept T/T (Telegraphic Transfer) and L/C (Letter of Credit). More flexible payment terms can be negotiated for long-term clients. Specific ratios (e.g., 30% down payment and 70% balance) can be adjusted based on the order value and credit status.


6. What processing services do you offer?
We provide services such as cutting, punching, bending, welding, uncoiling, and leveling. We also offer customized deep processing of profiles based on technical drawings. All processing is performed in-house to ensure quality control and timely delivery.
